Price list

Know the exact price* for all Maruti Suzuki cars here.

*Ex-showroom Price

HIGHLIGHTS

Speed Limiting Function

Extra Driving Comfort

low Cost of Ownership

Powerful Engine

Factory Fitted

Anti-lock Braking System

Reverse Parking Sensors

Driver Airbags

car
  • Dimensions

    Length

    3655 mm

    Width

    1620 mm

    Height

    1675 mm

    Wheelbase

    2435 mm

    Turning Radius

    4.7 mm

  • Engine

    Type

    K10C

    Capacity

    998 cc

    Number of cylinders

    3

    Maximum Engine Output (kW@rpm)

    41.7 kW @ 5300 rpm (CNG Mode)

    48.0 kW @ 5500 rpm (Petrol Mode)

    Maximum Torque (Nm@rpm)

    82.1 Nm @ 3400 rpm (CNG Mode)

    89.0 Nm @ 3500 rpm (Petrol Mode)

  • Suspension

    Front

    MacPherson Strut with Coil Spring

    Rear

    Torsion Beam with Coil Spring

  • Capacity

    Seating Capacity

    5

    Fuel Tank Capacity

    32 L (Petrol) / 60 L (CNG cylinder water filling capacity)

    Boot Space (Litres)

    341^ (Petrol)


    ^VDA Method.

  • Wheels & Tyres

    Size

    155/80R13

    Type

    Radial & Tubeless, Steel Wheels

  • Brakes

    Front

    Disc

    Rear

    Drum

  • Weight

    Gross Vehicle Weight

    1340 kg

    Kerb Weight

    910 kg

  • Drive & Transmission

    Transmission

    5 MT

  • Exteriors

    Body Colour Bumpers

    Wheel Centre Cap

    ORVM (Black)

    Outside Door Handles (Black)

    Grill (Black)

    Roof Antenna

  • Interiors

    Dual Tone Interiors

    Front Cabin Lamps (3 Positions)

    Driver Side Sunvisor with Ticket Holder

    Front and Rear Headrest (Integrated)

  • Central Console & Instrument Cluster

    Urethane Steering Wheel

    Instrument Cluster Meter Theme (Reddish Amber)

    Low Fuel Warning

    Gear Shift Indicator

    Fuel Consumption (Instantaneous & Avg.)

    Distance to Empty

    Headlamp On Warning

    Door Ajar Warning Lamp

  • Comfort and Convenience

    Accessory Socket Front Row with Storage Space

    Front Power Windows with Dr. Side Auto Down Function

    AC & Heater (Manual)

    1L Bottle Holders (All Four Doors + Floor Console)

    Rear Parcel Tray

    Reclining & Front Sliding Seats

    Outside Mirror Type (Pivot)

  • Safety And Security

    Driver Airbag

    Passenger Airbag

    ABS with EBD

    Pedestrian Protection

    Seat Belt Pre-tensioner & Force Limiters (Dr. +Co-Dr.)

    Seat Belt Reminder with Buzzer (Dr. +Co-Dr.)

    Speed Limiting Function (80km/h)

    Rear Parking Sensors

    Central Door Locking

  • Dimensions

    Length

    3655 mm

    Width

    1620 mm

    Height

    1675 mm

    Wheelbase

    2435 mm

    Turning Radius

    4.7 mm

  • Engine

    Type

    K10C

    Capacity

    998 cc

    Number of cylinders

    3

    Maximum Engine Output (kW@rpm)

    49.0 kW @ 5500 rpm

    Maximum Torque (Nm@rpm)

    89.0 Nm @ 3500 rpm

  • Suspension

    Front

    MacPherson Strut with Coil Spring

    Rear

    Torsion Beam with Coil Spring

  • Capacity

    Seating Capacity

    5

    Fuel Tank Capacity

    32 L

    Boot Space (Litres)

    341^ (Petrol)


    ^VDA Method.

  • Brakes

    Front

    Disc

    Rear

    Drum

  • Wheels & Tyres

    Size

    155/80R13

    Type

    Radial & Tubeless, Steel Wheels

  • Weight

    Gross Vehicle Weight

    1340 kg

    Kerb Weight

    810 kg

  • Transmission

    Transmission

    5 MT

  • Exteriors

    Body Colour Bumpers

    Wheel Centre Cap

    ORVM (Black)

    Outside Door Handles (Black)

    Grill (Black)

    Roof Antenna

  • Interiors

    Dual Tone Interiors

    Front Cabin Lamps (3 Positions)

    Driver Side Sunvisor with Ticket Holder

    Front and Rear Headrest (Integrated)

  • Central Console & Instrument Cluster

    Urethane Steering Wheel

    Instrument Cluster Meter Theme (Reddish Amber)

    Low Fuel Warning

    Gear Shift Indicator

    Fuel Consumption (Instantaneous & Avg.)

    Distance to Empty

    Headlamp On Warning

    Door Ajar Warning Lamp

  • Comfort & Convenience

    Idle Start Stop (ISS)

    Accessory Socket Front Row with Storage Space

    Front Power Windows with Dr. Side Auto Down Function

    AC & Heater (Manual)

    1L Bottle Holders (All Four Doors + Floor Console)

    Reclining & Front Sliding Seats

    Outside Mirror Type (Pivot)

  • Safety And Security

    Driver Airbag

    Passenger Airbag

    ABS with EBD

    Pedestrian Protection

    Seat Belt Pre-tensioner & Force Limiters (Dr. +Co-Dr.)

    Seat Belt Reminder with Buzzer (Dr. +Co-Dr.)

    Speed Limiting Function (80km/h)

    Rear Parking Sensors

    Central Door Locking

Wagon R New Engine

The Tour H3 is Powered by the 1.0 L Next Gen K-series Dual Jet Dual VVT Engine with Idle Start Stop Technology (In Petrol Variant) . It has manual air conditioner with heater, Front and Rear Integrated Headrest and Front power windows. All to make your customers relaxed and comfortable throughout the journey.

  • Petrol
    25.40 km/l#
  • CNG
    34.73 km/kg#
    • ...

#As certified by Test Agency Under Rule 115(G) of CMVR 1989

Wagon R ABS EBDWagon R ABS EBD

Maruti Suzuki Tour H3 is equipped with a host of safety features like Driver Airbags, ABS with EBD, Reverse Parking Sensors as standard, which ensure absolute safety for everyone

  • ABS with EBD
  • Driver Airbags
